Home » Hydraulic & Pneumatic Machines » Pneumatic Vibrators » Pneumatic Ball Vibrator MPBV-1
Pneumatic Ball Vibrator MPBV-1
₹ 3,227
₹ 5,500
41.33% Off Get Latest Price
| Brand | Others |
| Material | Aluminium |
| Temperature | Ambient |
| model | MPBV-1 |
| Product Type | Pneumatic Ball Vibrator |
GST No - 27APAPK0541H1ZA
Member since 2022
ground floor , omdhandai building , nr tmc school no 47, shivai nagar , pokhran road no 1 , thane west - 400606
PNEUMATIC BALL VIBRATOR MODEL MPBV-1 CENTRIFUGAL FORCE: 450 N @ 2 Bar , 800 N @ 4 Bar , 1100 N @ 6 Bar Pneumatic Vibrator , Ball Vibrator , Pneumatic Ball Vibrator Read More...
Related Products
₹ 4,200
| Automation Grade : Automatic |
| Color : Blue |
| Design : Printed |
| Material : Metal |
₹ 2,250
| Automation Grade : Automatic |
| I deal in : New Only |
| Material : Aluminium Body |
| model : Air Vibrator |
Pneumatic Piston Vibrators (BH-1.25)
₹ 9,500
| Air Supply : Compressed Air |
| Color : Blue Hammertone |
| model : Pneumatic Piston Vibrators (BH-1.25) |
| Standard Operation : BH 1.25 |
₹ 4,396
| Automation Grade : Semi-Automatic |
| Color : Multicolor |
| I Deal In : New Only |
| Material : Mild Steel |
₹ 95,000
| Automation Grade : Semi-Automatic |
| Brand : Shree Mona Fabricators |
| Capacity : 800 KG/H |
| Color : Silver |
₹ 4,000
| Minimum Order Quantity : 1 Number |
₹ 10,000
| Automation Grade : Automatic |
| Centrifugal Force : 27 kN |
| Frequency : 60 Hz |
| Material : Mild Steel |
NIKROM K8,K10,K20,K25,K30 Industrial Pneumatic Turbine Ball Vibrator., Air Pressure: 100Psi
₹ 1,750
| Air Consumption : 5 to 6 |
| Air Pressure : 100Psi |
| Brand : NIKROM |
| Country of Origin : Made in India |
₹ 750
| Color : Silver |
| Material : Aluminum |
| Minimum Order Quantity : 50 Piece |
| Proof temperature : 120 Degree C |
General Details
| model | MPBV-1 |
| Material | Aluminium |
| Temperature | Ambient |
| Product Type | Pneumatic Ball Vibrator |
Description
PNEUMATIC
BALL VIBRATOR MODEL MPBV-1
CENTRIFUGAL FORCE: 450 N @ 2 Bar , 800 N @ 4 Bar , 1100 N @ 6 Bar
Air Pressure
Frequency : 13000 VPM @ 2 Bar , 17000 VPM @ 4 Bar , 19500 VPM @ 6
Bar Air Pressure
Air Consumption : 122 LPM @ 2 Bar , 200 LPM @ 4
Bar , 280 LPM @ 6 Bar Air Pressure
WEIGHT 0.35 Kgs
Length – 113 mm , Height 65 mm
Width – 30 mm
Off White / Light Grey Colour
¼” BSP Inlet connector
1 Silencer at Outlet
Aluminium body for resistance to
weather and corrosion.
Pneumatic Ball vibrator is used for
ease in material flow. Best Solution for rat hole and bridging in Hoppers and
chutes.
Suitable for Small Hoppers upto 20 Kgs to 30 Kgs.
Hopper thickness should not be more than 2 mm.
(NOTE :- Hopper weight + material weight should not be more than 30
Kgs.)
About iMixx
iMixx, established in 2011 in Thane, Maharashtra is one of the leading manufacturers and sellers of Gates Doors Shutters & Security Barriers, Batching Plant Spares, Bulk Material Handling Equipment, Vibratory Equipment, Shutter Motors & Gate Motors Hardware, Weighing & Feeding Equipment, and More. Our products are widely used in various
read more...
ground floor , omdhandai building , nr tmc school no 47, shivai nagar , pokhran road no 1 , thane west - 400606
